Thông tin chi tiết sản phẩm:
|
| Sử dụng: | Dự án lò sưởi và lò sưởi khác | kháng hóa chất: | Chịu được xỉ axit và kiềm |
|---|---|---|---|
| Khúc xạ: | ≥1580oC | Hàm lượng carbon: | 99% |
| Kích cỡ: | Kích thước tiêu chuẩn như 230x114x65 mm hoặc tùy chỉnh | Độ xốp: | 10% - 30% |
| Cách xây dựng: | Daubing hoặc đúc | Nhiệt độ: | 1600 độ |
| Hàm lượng oxit canxi: | ≤15% | Sản phẩm: | Đồ gạch lửa |
| Chiều dài: | 1800mm-2700mm | TRO: | 0,3% |
| Kiểu: | Liên kết phosphate | Thành phần hóa học: | AL2O3-SIO2 |
| dịch vụcuộc sống: | Thông thường 3-10 năm tùy theo cách sử dụng | ||
| Làm nổi bật: | Rongsheng AZS refractory brick,zirconia corundum fused cast block,glass kiln refractory brick |
||
AZS bricks, also known as fused zirconia corundum bricks, are made by carefully selected zircon sand and industrial aluminum oxide powder in a 1:1 ratio, with a small amount of flux added, mixed evenly, melted at 1800~1900 ℃, and then cast into shape. Generally, zirconium corundum bricks can be divided into several grades according to the content of ZrO2, such as three grades of 33%, 36% and 41%. They have high melting point, good chemical stability, and strong corrosion resistance to acid and alkaline media, especially molten glass.
Features of AZS Brick
1.Casted by melting raw material in the mold, then cooling and solidification.
2.Strong glass corrosion resistance and high thermal shock stability.
3.Good wear-resistance,slag-resistance and alkali corrosion resistance.
4.High-purity raw material, barely no pollution.
5.Top quality, long service time.
Shapes and sizes: there are great variety of formats and shapes which are available for different forming and special machine processes.
Applications of AZS Brick
1.Sodium silicate furnace, ceramic frit furnace, glass furnace, etc..
2.Important parts of furnaces where chemical erosion is serious and temperature changes frequently.
3.Lining of glass furnace.
4.The chemical industrial, metallurgical furnaces.
Zirconium Corundum Bricks Properties:
| chemical composition | AZS-33 | AZS-36 | AZS-41 |
| ZrO2 | ≥33 | ≥35 | ≥40 |
| SiO2 | ≤16.0 | ≤14 | ≤13.0 |
| Al2O3 | a little | a little | a little |
| Na2O | ≤1.5 | ≤1.6 | ≤1.3 |
| Fe2O3+TiO2 | ≤0.3 | ≤0.3 | ≤0.3 |
Zirconium Corundum Bricks Physical Properties:
| bulk density(g/cm3): | 3.5-3.6 | 3.75 | 3.90 | |
| cold crushing Mpa | 350 | 350 | 350 | |
| thermal expansion coefficient (1000°C) | 0.80 | 0.80 | 0.80 | |
| exudation temp. of glass phase | 1400 | 1400 | 1400 | |
| corrocion resistance of glass melt(mm/24h) | 1.6 | 1.5 | 1.3 | |
| Density | PT QX | 3.40 | 3.45 | 3.55 |
| WS ZWS | 3.60 | 3.70 | 3.8 | |
Zirconium Corundum Bricks Phase Composition(%):
| baddeleyite | 32 | 35 | 40 |
| glass phase | 21 | 18 | 17 |
| α- corundum | 47 | 47 | 43 |
